>> P.372
ReplacingbezelsandgraduationplatesAbezelandgraduationplatemustbeswagedtogethersothatthegraduationplatealwaysrotateswiththebezel.Assembliescomprisedofaswagedbezelandgraduationplateareavailableforsomemodels.CodeNo.ofdialindicators2046A2109A-10CodeNo.ofswagedassemblies21AZB65021AZB693SpindleLiftingLeverandCableOptionalAccessoriesforDigimaticandDialIndicatorsDialIndicatorRepairToolKit(15)(13)(14)(17)(6)(7)(8)(11)(9)(23)(22)(5)(16)(10)SetcodeNo.7823EUSetConguration(1)Spindlerest(129730)(2)Pinremover(129732)(3)Punch(129733)(4)Bearingadjuster(129734)(5)Pinionrest(129735)(6)Reamer(ø1:1/50taper)(129736)(7)Reamer(ø0.6:1/50taper)(193702)(8)Reamerforpointer(ø0.5:1/20taper)(21JAA273)(9)Pointerremovingtool(126628)(10)Softtouchpliers(21JAA371)(11)Nippers(901179)(12)Pinrest(129731)(13)Hammer(901178)(14)Stick(21JAA314)(15)Brush(901177)(16)Bamboobrush(901176)(17)Pin-vise(901175)(18)Screwdriver(Phillips/atblade)(901174)(19)Tweezers(129729)(20)Screwdriver(Phillips)(901173)(21)Pointerremovingtip(ø0.8)(126630)(22)Pointerremovingtip(ø0.5)(126630B)(23)Pointerremovingtip(ø1.6)(126630C)(24)Adjustablenut(100699)ReplacethelongorlittlehandScrewthepinionrest(No.5)intothepinrest(No.12).Supportthepinionwiththexedpinionrest,andreplacethehandwiththepunch(No.3)andhammer(No.13).Reamingisnecessarywhenreplacingwithanewhand.Usereamersasfollows:•ThehandsofDGSeriesA-typeandTI-XSeries*1dialtestindicatorsdonotrequirereaming.•Usethereamerforpointer(No.8)(ø0.5:1/20taper)forStypeandTtypedialindicators*2.•Dependingontheshaftdiameter,usereamer(No.6)(ø1:1/50taper)orreamer(No.7)(ø0.6:1/50taper)forFtypedialindicatorsandotherthanTI-XSeriesdialtestindicators.(3)(2)(20)(4)(18)(19)(12)(21)(24)(1)TypicalapplicationsRemovethelonghandPositionthepointerremovingtool(No.9)ontheholediameteroftheminutehand.Pushthepivotwiththepointerremovingtooltoremovethelonghand.RemovethelittlehandRemovethelittlehandwiththenippers(No.11).AdjustabearingPressthesteelorjeweledbearingintoitshousingusingthebearingadjuster(No.4).RemoveorreplaceapinPlacethespindleonthegrooveofthespindlerest(No.1).Removethepinwiththepinremover(No.2)andthehammer(No.13).Tapthepindirectlywiththehammer(No.13)toreplacethepin.*1DialtestindicatorwhosemodelNo.endsin“X”.*2DialindicatorwhosecodeNo.includesan“S”,“T”and“A”.07-73
| <
|
> |
>>
